TruViz Phob
Hydrophobic Aspheric 360' & Square Edge Foldable
Hydrophobic Aspheric 360' & Square Edge Foldable
THF 603
| Optic Diameter | 6.00 mm |
| Overall Diameter | 12.50 mm |
| Optic Design | Aberration Neutral, Negative Aspheric Biconvex/td> |
| Haptic Design | ?C? Design, 0? Angulation |
| PCO Protection | 360? perfect Square edge around the optic edge |
| Suggested A. Constant | 118.0 |
| Refractive Index @ 25?C | 1.4933 |
| Lens Material | Hydrophobic Acrylic |
| Delivery System | Disposable Injector cartridge 2.20 mm to 2.60 mm Incission |
| Available Diopters | -5.0 D to + 35.0 D ( +10.0D to + 30.0 D in 0.5 D steps, -5.0 D to + 9.0 D & + 31.0 to + 35.0 D in 1.0 D Steps) |
THF 604
| Optic Diameter | 6.00 mm |
| Overall Diameter | 13.00 mm |
| Optic Design | Aberration Neutral, Negative Aspheric Biconvex |
| Haptic Design | ?C? Design, 0? Angulation |
| PCO Protection | 360? perfect Square edge around the optic edge |
| Suggested A. Constant | 118.0 |
| Refractive Index @ 25?C | 1.4933 |
| Lens Material | Hydrophobic Acrylic |
| Delivery System | Disposable Injector cartridge 2.20 mm to 2.60 mm Incission |
| Available Diopters | -5.0 D to + 35.0 D ( +10.0D to + 30.0 D in 0.5 D steps, -5.0 D to + 9.0 D & + 31.0 to + 35.0 D in 1.0 D Steps) |
THF 603Y
| Optic Diameter | 6.00 mm |
| Overall Diameter | 12.50 mm |
| Optic Design | Aberration Neutral, Negative Aspheric Biconvex |
| Haptic Design | ?C? Design, 0? Angulation |
| PCO Protection | 360? perfect Square edge around the optic edge |
| Suggested A. Constant | 118.0 |
| Refractive Index @ 25?C | 1.4933 |
| Lens Material | Hydrophobic Acrylic |
| Delivery System | Disposable Injector cartridge 2.20 mm to 2.60 mm Incission |
| Available Diopters | -5.0 D to + 35.0 D ( +10.0D to + 30.0 D in 0.5 D steps, -5.0 D to + 9.0 D & + 31.0 to + 35.0 D in 1.0 D Steps) |
THF 604Y
| Optic Diameter | 6.00 mm |
| Overall Diameter | 13.00 mm |
| Optic Design | Aberration Neutral, Negative Aspheric Biconvex |
| Haptic Design | ?C? Design, 0? Angulation |
| PCO Protection | 360? perfect Square edge around the optic edge |
| Suggested A. Constant | 118.0 |
| Refractive Index @ 25?C | 1.4933 |
| Lens Material | Hydrophobic Acrylic |
| Delivery System | Disposable Injector cartridge 2.20 mm to 2.60 mm Incission |
| Available Diopters | -5.0 D to + 35.0 D ( +10.0D to + 30.0 D in 0.5 D steps, -5.0 D to + 9.0 D & + 31.0 to + 35.0 D in 1.0 D Steps) |
TruViz Multifocal
Single Piece Hydrophobic Acrylic Diffractive & Refractive Lenses
TMHF 603SQ
| Power | +5.0 D to 34.0 D in 0.5 Diopter Increments |
| Diameter | 6.00 mm |
| Shape | Biconvex, Anterior Diffractive, Posterior Aspheric |
| Material | UV-Blocking Hydrophobic Acrylic |
| Refractive Index | 1.4933 |
| Chromatic Abberation | 55 |
| Edge Design | Continuous 360? posterior Square Edge |
| A.Constant | 118.8 |
| Overall Length | 12.50mm |
| Style | C |
| Material | UV-Blocking Hydrophobic Acrylic |
| Design | Haptics offset from Optic |
| Add Power | +3.00 D, +3.50 D, +4.00 D |
